Implementing Logistic Regression with Scikit-learn

Learn to implement logistic regression with scikit-learn step by step. Covers solvers, regularization, multi-class, hyperparameter tuning, and full evaluation pipelines.

By Techietory on February 20, 2026

Implementing logistic regression with scikit-learn requires four steps: importing and splitting data, scaling features with StandardScaler, fitting a LogisticRegression model, and evaluating with metrics like accuracy, classification_report, and roc_auc_score. Scikit-learn’s LogisticRegression class handles binary and multi-class problems, supports L1/L2/ElasticNet regularization through the penalty parameter, and offers multiple solvers optimized for different data sizes. The parameter C controls regularization strength (smaller C = stronger regularization), and predict_proba() returns class probabilities essential for threshold tuning and ROC curve analysis.

Introduction: From Theory to Working Code

The previous articles established the theory behind logistic regression: the sigmoid function squashing linear outputs into probabilities, the binary cross-entropy cost function, gradient descent optimizing the weights, and the decision boundary separating the two classes. Now it is time to move from equations to working, production-quality code.

Scikit-learn’s LogisticRegression class encapsulates all that theory into a clean, consistent API that follows the same fit() / predict() / score() interface used by every other estimator in the library. Behind that simple interface lies a highly optimized implementation with multiple solvers, regularization options, multi-class strategies, and robust convergence handling — far more capable than the from-scratch version built in article 52.

This guide is deliberately practical. Every concept is grounded in runnable code. You will build a complete classification workflow from raw data to deployed model, understand every parameter of LogisticRegression, learn when to use each solver and regularization option, handle the full range of real-world complications (imbalanced classes, multi-class problems, hyperparameter tuning), and produce publication-quality evaluation reports.

By the end, you will have a reusable logistic regression template you can apply to any binary or multi-class classification problem.

The Scikit-learn API: Core Concepts

Before diving into logistic regression specifically, understanding scikit-learn’s universal API makes everything else click.

The Estimator Interface

Python

# Every scikit-learn model follows this pattern:

# 1. Import
from sklearn.linear_model import LogisticRegression

# 2. Instantiate (set hyperparameters)
model = LogisticRegression(C=1.0, max_iter=1000)

# 3. Fit (learn from training data)
model.fit(X_train, y_train)

# 4. Predict
y_pred  = model.predict(X_test)        # Class labels: 0 or 1
y_proba = model.predict_proba(X_test)  # Probabilities: [[p0, p1], ...]

# 5. Evaluate
score = model.score(X_test, y_test)    # Returns accuracy by default

# Every scikit-learn model follows this pattern:

# 1. Import
from sklearn.linear_model import LogisticRegression

# 2. Instantiate (set hyperparameters)
model = LogisticRegression(C=1.0, max_iter=1000)

# 3. Fit (learn from training data)
model.fit(X_train, y_train)

# 4. Predict
y_pred  = model.predict(X_test)        # Class labels: 0 or 1
y_proba = model.predict_proba(X_test)  # Probabilities: [[p0, p1], ...]

# 5. Evaluate
score = model.score(X_test, y_test)    # Returns accuracy by default

Learned Attributes (Available After fit())

Python

model.fit(X_train, y_train)

# What the model learned:
print(model.coef_)          # Weight matrix — shape: (1, n_features) for binary
print(model.intercept_)     # Bias term — shape: (1,) for binary
print(model.classes_)       # Class labels: array([0, 1])
print(model.n_iter_)        # Actual iterations until convergence
print(model.n_features_in_) # Number of features seen during fit

model.fit(X_train, y_train)

# What the model learned:
print(model.coef_)          # Weight matrix — shape: (1, n_features) for binary
print(model.intercept_)     # Bias term — shape: (1,) for binary
print(model.classes_)       # Class labels: array([0, 1])
print(model.n_iter_)        # Actual iterations until convergence
print(model.n_features_in_) # Number of features seen during fit

Environment Setup and Data Preparation

Python

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import warnings
warnings.filterwarnings('ignore')

from sklearn.linear_model    import LogisticRegression
from sklearn.model_selection import (train_test_split, StratifiedKFold,
                                     cross_val_score, GridSearchCV,
                                     learning_curve)
from sklearn.preprocessing   import StandardScaler, LabelEncoder
from sklearn.pipeline        import Pipeline
from sklearn.metrics         import (accuracy_score, precision_score,
                                     recall_score, f1_score,
                                     roc_auc_score, roc_curve,
                                     confusion_matrix,
                                     classification_report,
                                     ConfusionMatrixDisplay,
                                     precision_recall_curve,
                                     average_precision_score)
from sklearn.datasets        import (load_breast_cancer, load_iris,
                                     make_classification)

print("All imports successful.")
print(f"scikit-learn version: {__import__('sklearn').__version__}")

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import warnings
warnings.filterwarnings('ignore')

from sklearn.linear_model    import LogisticRegression
from sklearn.model_selection import (train_test_split, StratifiedKFold,
                                     cross_val_score, GridSearchCV,
                                     learning_curve)
from sklearn.preprocessing   import StandardScaler, LabelEncoder
from sklearn.pipeline        import Pipeline
from sklearn.metrics         import (accuracy_score, precision_score,
                                     recall_score, f1_score,
                                     roc_auc_score, roc_curve,
                                     confusion_matrix,
                                     classification_report,
                                     ConfusionMatrixDisplay,
                                     precision_recall_curve,
                                     average_precision_score)
from sklearn.datasets        import (load_breast_cancer, load_iris,
                                     make_classification)

print("All imports successful.")
print(f"scikit-learn version: {__import__('sklearn').__version__}")

Dataset 1: Binary Classification — Breast Cancer

The breast cancer dataset is the canonical binary classification benchmark: 569 examples, 30 features, two classes (malignant vs. benign).

Loading and Exploring

Python

# ── Load dataset ────────────────────────────────────────────────
cancer = load_breast_cancer()
X, y   = cancer.data, cancer.target

print("=" * 50)
print("  Breast Cancer Dataset")
print("=" * 50)
print(f"  Examples:   {X.shape[0]}")
print(f"  Features:   {X.shape[1]}")
print(f"  Classes:    {cancer.target_names}")
print(f"  Class 0 (malignant): {(y==0).sum()} ({(y==0).mean()*100:.1f}%)")
print(f"  Class 1 (benign):    {(y==1).sum()} ({(y==1).mean()*100:.1f}%)")
print()

# Quick peek at features
df = pd.DataFrame(X, columns=cancer.feature_names)
df['target'] = y
print("Feature statistics (first 5 features):")
print(df.iloc[:, :5].describe().round(3))

# ── Load dataset ────────────────────────────────────────────────
cancer = load_breast_cancer()
X, y   = cancer.data, cancer.target

print("=" * 50)
print("  Breast Cancer Dataset")
print("=" * 50)
print(f"  Examples:   {X.shape[0]}")
print(f"  Features:   {X.shape[1]}")
print(f"  Classes:    {cancer.target_names}")
print(f"  Class 0 (malignant): {(y==0).sum()} ({(y==0).mean()*100:.1f}%)")
print(f"  Class 1 (benign):    {(y==1).sum()} ({(y==1).mean()*100:.1f}%)")
print()

# Quick peek at features
df = pd.DataFrame(X, columns=cancer.feature_names)
df['target'] = y
print("Feature statistics (first 5 features):")
print(df.iloc[:, :5].describe().round(3))

Output:

Plaintext

==================================================
  Breast Cancer Dataset
==================================================
  Examples:   569
  Features:   30
  Classes:    ['malignant' 'benign']
  Class 0 (malignant): 212 (37.3%)
  Class 1 (benign):    357 (62.7%)

==================================================
  Breast Cancer Dataset
==================================================
  Examples:   569
  Features:   30
  Classes:    ['malignant' 'benign']
  Class 0 (malignant): 212 (37.3%)
  Class 1 (benign):    357 (62.7%)

Train-Test Split

Python

# Stratify ensures both splits preserve the class ratio
X_train, X_test, y_train, y_test = train_test_split(
    X, y,
    test_size=0.2,
    random_state=42,
    stratify=y          # Critical for classification splits
)

print(f"Training set:  {X_train.shape[0]} examples")
print(f"Test set:      {X_test.shape[0]} examples")
print(f"Train class 1: {y_train.mean()*100:.1f}%")
print(f"Test  class 1: {y_test.mean()*100:.1f}%")
# Both should be ~62.7% — stratify worked

# Stratify ensures both splits preserve the class ratio
X_train, X_test, y_train, y_test = train_test_split(
    X, y,
    test_size=0.2,
    random_state=42,
    stratify=y          # Critical for classification splits
)

print(f"Training set:  {X_train.shape[0]} examples")
print(f"Test set:      {X_test.shape[0]} examples")
print(f"Train class 1: {y_train.mean()*100:.1f}%")
print(f"Test  class 1: {y_test.mean()*100:.1f}%")
# Both should be ~62.7% — stratify worked

Feature Scaling

Python

# Logistic regression uses gradient-based optimization →
# features must be on similar scales for stable convergence.
# StandardScaler: mean=0, std=1 per feature.

scaler    = StandardScaler()
X_train_s = scaler.fit_transform(X_train)   # Fit on train ONLY
X_test_s  = scaler.transform(X_test)        # Apply same transform to test

print("Before scaling (first feature):")
print(f"  mean={X_train[:, 0].mean():.2f},  std={X_train[:, 0].std():.2f}")
print("After scaling (first feature):")
print(f"  mean={X_train_s[:, 0].mean():.4f}, std={X_train_s[:, 0].std():.4f}")

# Logistic regression uses gradient-based optimization →
# features must be on similar scales for stable convergence.
# StandardScaler: mean=0, std=1 per feature.

scaler    = StandardScaler()
X_train_s = scaler.fit_transform(X_train)   # Fit on train ONLY
X_test_s  = scaler.transform(X_test)        # Apply same transform to test

print("Before scaling (first feature):")
print(f"  mean={X_train[:, 0].mean():.2f},  std={X_train[:, 0].std():.2f}")
print("After scaling (first feature):")
print(f"  mean={X_train_s[:, 0].mean():.4f}, std={X_train_s[:, 0].std():.4f}")

The LogisticRegression Class: Every Parameter Explained

Python

# Full parameter signature with explanations:
model = LogisticRegression(
    penalty='l2',          # Regularization type: 'l1', 'l2', 'elasticnet', None
    C=1.0,                 # Inverse regularization strength (larger = less regular)
    fit_intercept=True,    # Whether to add a bias term
    class_weight=None,     # Handle class imbalance: None, 'balanced', or dict
    random_state=42,       # Seed for reproducibility (used by some solvers)
    solver='lbfgs',        # Optimization algorithm (see below)
    max_iter=1000,         # Maximum iterations for solver convergence
    multi_class='auto',    # 'auto', 'ovr', 'multinomial'
    verbose=0,             # Print convergence info: 0=silent, 1=progress
    warm_start=False,      # Reuse previous fit's solution as starting point
    n_jobs=None,           # Parallel jobs for OvR multi-class (-1 = all CPUs)
    l1_ratio=None,         # ElasticNet mixing (only when penalty='elasticnet')
    tol=1e-4,              # Tolerance for stopping criterion
)

# Full parameter signature with explanations:
model = LogisticRegression(
    penalty='l2',          # Regularization type: 'l1', 'l2', 'elasticnet', None
    C=1.0,                 # Inverse regularization strength (larger = less regular)
    fit_intercept=True,    # Whether to add a bias term
    class_weight=None,     # Handle class imbalance: None, 'balanced', or dict
    random_state=42,       # Seed for reproducibility (used by some solvers)
    solver='lbfgs',        # Optimization algorithm (see below)
    max_iter=1000,         # Maximum iterations for solver convergence
    multi_class='auto',    # 'auto', 'ovr', 'multinomial'
    verbose=0,             # Print convergence info: 0=silent, 1=progress
    warm_start=False,      # Reuse previous fit's solution as starting point
    n_jobs=None,           # Parallel jobs for OvR multi-class (-1 = all CPUs)
    l1_ratio=None,         # ElasticNet mixing (only when penalty='elasticnet')
    tol=1e-4,              # Tolerance for stopping criterion
)

Understanding the C Parameter (Regularization)

Python

# C = 1/λ where λ is regularization strength
# Small C → Strong regularization → Simpler model
# Large C → Weak regularization  → Complex model (may overfit)

C_values    = [0.001, 0.01, 0.1, 1.0, 10.0, 100.0]
train_accs  = []
test_accs   = []
n_nonzero   = []

for C in C_values:
    m = LogisticRegression(C=C, max_iter=2000, random_state=42)
    m.fit(X_train_s, y_train)
    train_accs.append(m.score(X_train_s, y_train))
    test_accs.append(m.score(X_test_s, y_test))
    n_nonzero.append(np.sum(np.abs(m.coef_[0]) > 1e-6))

print(f"{'C':>8} {'Train Acc':>10} {'Test Acc':>10} {'NonZero W':>10}")
print("-" * 42)
for C, tr, te, nz in zip(C_values, train_accs, test_accs, n_nonzero):
    print(f"{C:>8.3f} {tr:>10.4f} {te:>10.4f} {nz:>10d}")

# C = 1/λ where λ is regularization strength
# Small C → Strong regularization → Simpler model
# Large C → Weak regularization  → Complex model (may overfit)

C_values    = [0.001, 0.01, 0.1, 1.0, 10.0, 100.0]
train_accs  = []
test_accs   = []
n_nonzero   = []

for C in C_values:
    m = LogisticRegression(C=C, max_iter=2000, random_state=42)
    m.fit(X_train_s, y_train)
    train_accs.append(m.score(X_train_s, y_train))
    test_accs.append(m.score(X_test_s, y_test))
    n_nonzero.append(np.sum(np.abs(m.coef_[0]) > 1e-6))

print(f"{'C':>8} {'Train Acc':>10} {'Test Acc':>10} {'NonZero W':>10}")
print("-" * 42)
for C, tr, te, nz in zip(C_values, train_accs, test_accs, n_nonzero):
    print(f"{C:>8.3f} {tr:>10.4f} {te:>10.4f} {nz:>10d}")

Output:

Plaintext

       C  Train Acc   Test Acc  NonZero W
------------------------------------------
   0.001     0.9363     0.9386         30
   0.010     0.9648     0.9561         30
   0.100     0.9780     0.9649         30
   1.000     0.9868     0.9737         30
  10.000     0.9912     0.9737         30
 100.000     0.9934     0.9649         30

       C  Train Acc   Test Acc  NonZero W
------------------------------------------
   0.001     0.9363     0.9386         30
   0.010     0.9648     0.9561         30
   0.100     0.9780     0.9649         30
   1.000     0.9868     0.9737         30
  10.000     0.9912     0.9737         30
 100.000     0.9934     0.9649         30

C=1.0 and C=10.0 both achieve the same test accuracy — good regularization range. C=100.0 starts overfitting (train accuracy increases but test stays same or drops).

Understanding Solvers

Python

# Solver comparison — choose based on data size and penalty type

solvers_info = {
    'lbfgs': {
        'penalties':   ['l2', None],
        'best_for':    'Small-medium datasets, L2 regularization (default)',
        'multiclass':  'multinomial natively',
        'speed':       'Fast convergence, memory-efficient',
    },
    'liblinear': {
        'penalties':   ['l1', 'l2'],
        'best_for':    'Small datasets, L1 regularization, binary problems',
        'multiclass':  'OvR only',
        'speed':       'Very fast for small data',
    },
    'saga': {
        'penalties':   ['l1', 'l2', 'elasticnet', None],
        'best_for':    'Large datasets, all penalty types',
        'multiclass':  'multinomial',
        'speed':       'Stochastic — fast for large data',
    },
    'sag': {
        'penalties':   ['l2', None],
        'best_for':    'Large datasets, L2 only',
        'multiclass':  'multinomial',
        'speed':       'Stochastic — fast for large data',
    },
    'newton-cg': {
        'penalties':   ['l2', None],
        'best_for':    'Medium datasets, L2',
        'multiclass':  'multinomial',
        'speed':       'Second-order, accurate but slower',
    },
}

print("Solver Selection Guide:")
print("-" * 60)
for solver, info in solvers_info.items():
    print(f"\n  {solver.upper()}")
    print(f"    Penalties:  {info['penalties']}")
    print(f"    Best for:   {info['best_for']}")

# Practical rule: start with lbfgs (default), switch to saga for large data
# or when you need l1/elasticnet regularization

# Solver comparison — choose based on data size and penalty type

solvers_info = {
    'lbfgs': {
        'penalties':   ['l2', None],
        'best_for':    'Small-medium datasets, L2 regularization (default)',
        'multiclass':  'multinomial natively',
        'speed':       'Fast convergence, memory-efficient',
    },
    'liblinear': {
        'penalties':   ['l1', 'l2'],
        'best_for':    'Small datasets, L1 regularization, binary problems',
        'multiclass':  'OvR only',
        'speed':       'Very fast for small data',
    },
    'saga': {
        'penalties':   ['l1', 'l2', 'elasticnet', None],
        'best_for':    'Large datasets, all penalty types',
        'multiclass':  'multinomial',
        'speed':       'Stochastic — fast for large data',
    },
    'sag': {
        'penalties':   ['l2', None],
        'best_for':    'Large datasets, L2 only',
        'multiclass':  'multinomial',
        'speed':       'Stochastic — fast for large data',
    },
    'newton-cg': {
        'penalties':   ['l2', None],
        'best_for':    'Medium datasets, L2',
        'multiclass':  'multinomial',
        'speed':       'Second-order, accurate but slower',
    },
}

print("Solver Selection Guide:")
print("-" * 60)
for solver, info in solvers_info.items():
    print(f"\n  {solver.upper()}")
    print(f"    Penalties:  {info['penalties']}")
    print(f"    Best for:   {info['best_for']}")

# Practical rule: start with lbfgs (default), switch to saga for large data
# or when you need l1/elasticnet regularization

Solver Performance Comparison

Python

import time

solvers_to_test = {
    'lbfgs':      LogisticRegression(solver='lbfgs',      C=1.0, max_iter=2000),
    'liblinear':  LogisticRegression(solver='liblinear',  C=1.0, max_iter=2000),
    'saga':       LogisticRegression(solver='saga',       C=1.0, max_iter=2000,
                                      random_state=42),
    'newton-cg':  LogisticRegression(solver='newton-cg',  C=1.0, max_iter=2000),
}

print(f"{'Solver':>12} {'Time (ms)':>10} {'Train Acc':>10} {'Test Acc':>10} {'Iters':>7}")
print("-" * 55)

for name, m in solvers_to_test.items():
    t0 = time.time()
    m.fit(X_train_s, y_train)
    elapsed = (time.time() - t0) * 1000

    print(f"{name:>12} {elapsed:>10.1f} "
          f"{m.score(X_train_s, y_train):>10.4f} "
          f"{m.score(X_test_s, y_test):>10.4f} "
          f"{m.n_iter_[0]:>7d}")

import time

solvers_to_test = {
    'lbfgs':      LogisticRegression(solver='lbfgs',      C=1.0, max_iter=2000),
    'liblinear':  LogisticRegression(solver='liblinear',  C=1.0, max_iter=2000),
    'saga':       LogisticRegression(solver='saga',       C=1.0, max_iter=2000,
                                      random_state=42),
    'newton-cg':  LogisticRegression(solver='newton-cg',  C=1.0, max_iter=2000),
}

print(f"{'Solver':>12} {'Time (ms)':>10} {'Train Acc':>10} {'Test Acc':>10} {'Iters':>7}")
print("-" * 55)

for name, m in solvers_to_test.items():
    t0 = time.time()
    m.fit(X_train_s, y_train)
    elapsed = (time.time() - t0) * 1000

    print(f"{name:>12} {elapsed:>10.1f} "
          f"{m.score(X_train_s, y_train):>10.4f} "
          f"{m.score(X_test_s, y_test):>10.4f} "
          f"{m.n_iter_[0]:>7d}")

Complete Binary Classification Pipeline

Using Pipeline (Best Practice)

Python

# Pipeline chains preprocessing + model into one object.
# Prevents data leakage: scaler fits only on training fold.

pipe = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   random_state=42))
])

# fit() on pipeline: scaler.fit_transform(X_train) → clf.fit(X_train_scaled)
pipe.fit(X_train, y_train)

# predict() on pipeline: scaler.transform(X_test) → clf.predict(X_test_scaled)
y_pred  = pipe.predict(X_test)
y_proba = pipe.predict_proba(X_test)[:, 1]   # P(class=1)

print("Pipeline predictions (first 10):")
print("  Predicted:", y_pred[:10])
print("  Actual:   ", y_test[:10])
print("  P(class1):", y_proba[:10].round(3))

# Pipeline chains preprocessing + model into one object.
# Prevents data leakage: scaler fits only on training fold.

pipe = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   random_state=42))
])

# fit() on pipeline: scaler.fit_transform(X_train) → clf.fit(X_train_scaled)
pipe.fit(X_train, y_train)

# predict() on pipeline: scaler.transform(X_test) → clf.predict(X_test_scaled)
y_pred  = pipe.predict(X_test)
y_proba = pipe.predict_proba(X_test)[:, 1]   # P(class=1)

print("Pipeline predictions (first 10):")
print("  Predicted:", y_pred[:10])
print("  Actual:   ", y_test[:10])
print("  P(class1):", y_proba[:10].round(3))

Comprehensive Evaluation

Python

def full_evaluation(y_true, y_pred, y_proba,
                    class_names=None, model_name="Model"):
    """
    Complete binary classification evaluation report.
    Prints metrics and returns a results dictionary.
    """
    if class_names is None:
        class_names = ['Class 0', 'Class 1']

    acc  = accuracy_score(y_true, y_pred)
    prec = precision_score(y_true, y_pred)
    rec  = recall_score(y_true, y_pred)
    f1   = f1_score(y_true, y_pred)
    auc  = roc_auc_score(y_true, y_proba)
    ap   = average_precision_score(y_true, y_proba)

    print(f"\n{'='*55}")
    print(f"  {model_name}")
    print(f"{'='*55}")
    print(f"  Accuracy:          {acc:.4f}")
    print(f"  Precision:         {prec:.4f}")
    print(f"  Recall:            {rec:.4f}")
    print(f"  <a href="https://techietory.com/ai/f1-score-imbalanced-datasets/">F1 Score</a>:          {f1:.4f}")
    print(f"  ROC-AUC:           {auc:.4f}")
    print(f"  Avg Precision:     {ap:.4f}")
    print(f"\n{classification_report(y_true, y_pred, target_names=class_names)}")

    return dict(accuracy=acc, precision=prec, recall=rec,
                f1=f1, roc_auc=auc, avg_precision=ap)

results = full_evaluation(
    y_test, y_pred, y_proba,
    class_names=cancer.target_names,
    model_name="Logistic Regression — Breast Cancer"
)

def full_evaluation(y_true, y_pred, y_proba,
                    class_names=None, model_name="Model"):
    """
    Complete binary classification evaluation report.
    Prints metrics and returns a results dictionary.
    """
    if class_names is None:
        class_names = ['Class 0', 'Class 1']

    acc  = accuracy_score(y_true, y_pred)
    prec = precision_score(y_true, y_pred)
    rec  = recall_score(y_true, y_pred)
    f1   = f1_score(y_true, y_pred)
    auc  = roc_auc_score(y_true, y_proba)
    ap   = average_precision_score(y_true, y_proba)

    print(f"\n{'='*55}")
    print(f"  {model_name}")
    print(f"{'='*55}")
    print(f"  Accuracy:          {acc:.4f}")
    print(f"  Precision:         {prec:.4f}")
    print(f"  Recall:            {rec:.4f}")
    print(f"  F1 Score:          {f1:.4f}")
    print(f"  ROC-AUC:           {auc:.4f}")
    print(f"  Avg Precision:     {ap:.4f}")
    print(f"\n{classification_report(y_true, y_pred, target_names=class_names)}")

    return dict(accuracy=acc, precision=prec, recall=rec,
                f1=f1, roc_auc=auc, avg_precision=ap)

results = full_evaluation(
    y_test, y_pred, y_proba,
    class_names=cancer.target_names,
    model_name="Logistic Regression — Breast Cancer"
)

Expected Output:

Plaintext

=======================================================
  Logistic Regression — Breast Cancer
=======================================================
  Accuracy:          0.9737
  Precision:         0.9718
  Recall:            0.9859
  F1 Score:          0.9788
  ROC-AUC:           0.9975
  Avg Precision:     0.9979

              precision    recall  f1-score   support
   malignant       0.975      0.951      0.963        41
      benign       0.972      0.986      0.979        73
    accuracy                            0.974       114
   macro avg       0.974      0.969      0.971       114
weighted avg       0.974      0.974      0.974       114

=======================================================
  Logistic Regression — Breast Cancer
=======================================================
  Accuracy:          0.9737
  Precision:         0.9718
  Recall:            0.9859
  F1 Score:          0.9788
  ROC-AUC:           0.9975
  Avg Precision:     0.9979

              precision    recall  f1-score   support
   malignant       0.975      0.951      0.963        41
      benign       0.972      0.986      0.979        73
    accuracy                            0.974       114
   macro avg       0.974      0.969      0.971       114
weighted avg       0.974      0.974      0.974       114

Visualizing Results

Python

fig, axes = plt.subplots(1, 3, figsize=(16, 5))

# ── 1. <a href="https://techietory.com/ai/understanding-confusion-matrices-classification/">Confusion Matrix</a> ─────────────────────────────────────────
cm  = confusion_matrix(y_test, y_pred)
disp = ConfusionMatrixDisplay(cm, display_labels=cancer.target_names)
disp.plot(ax=axes[0], colorbar=False, cmap='Blues')
axes[0].set_title('Confusion Matrix', fontsize=12)

# ── 2. ROC Curve ────────────────────────────────────────────────
fpr, tpr, thresholds_roc = roc_curve(y_test, y_proba)
auc_score = roc_auc_score(y_test, y_proba)

axes[1].plot(fpr, tpr, 'steelblue', linewidth=2,
             label=f'LR (AUC = {auc_score:.3f})')
axes[1].plot([0, 1], [0, 1], 'k--', linewidth=1, label='Random')
axes[1].fill_between(fpr, tpr, alpha=0.15, color='steelblue')
axes[1].set_xlabel('False Positive Rate')
axes[1].set_ylabel('True Positive Rate')
axes[1].set_title('ROC Curve')
axes[1].legend()
axes[1].grid(True, alpha=0.3)

# ── 3. Precision-Recall Curve ───────────────────────────────────
prec_c, rec_c, _ = precision_recall_curve(y_test, y_proba)
ap_score = average_precision_score(y_test, y_proba)

axes[2].plot(rec_c, prec_c, 'coral', linewidth=2,
             label=f'LR (AP = {ap_score:.3f})')
axes[2].axhline(y_test.mean(), color='k', linestyle='--',
                linewidth=1, label=f'Baseline ({y_test.mean():.2f})')
axes[2].set_xlabel('Recall')
axes[2].set_ylabel('Precision')
axes[2].set_title('Precision-Recall Curve')
axes[2].legend()
axes[2].grid(True, alpha=0.3)

plt.suptitle('Logistic Regression — Breast Cancer Evaluation',
             fontsize=13, fontweight='bold')
plt.tight_layout()
plt.show()

fig, axes = plt.subplots(1, 3, figsize=(16, 5))

# ── 1. Confusion Matrix ─────────────────────────────────────────
cm  = confusion_matrix(y_test, y_pred)
disp = ConfusionMatrixDisplay(cm, display_labels=cancer.target_names)
disp.plot(ax=axes[0], colorbar=False, cmap='Blues')
axes[0].set_title('Confusion Matrix', fontsize=12)

# ── 2. ROC Curve ────────────────────────────────────────────────
fpr, tpr, thresholds_roc = roc_curve(y_test, y_proba)
auc_score = roc_auc_score(y_test, y_proba)

axes[1].plot(fpr, tpr, 'steelblue', linewidth=2,
             label=f'LR (AUC = {auc_score:.3f})')
axes[1].plot([0, 1], [0, 1], 'k--', linewidth=1, label='Random')
axes[1].fill_between(fpr, tpr, alpha=0.15, color='steelblue')
axes[1].set_xlabel('False Positive Rate')
axes[1].set_ylabel('True Positive Rate')
axes[1].set_title('ROC Curve')
axes[1].legend()
axes[1].grid(True, alpha=0.3)

# ── 3. Precision-Recall Curve ───────────────────────────────────
prec_c, rec_c, _ = precision_recall_curve(y_test, y_proba)
ap_score = average_precision_score(y_test, y_proba)

axes[2].plot(rec_c, prec_c, 'coral', linewidth=2,
             label=f'LR (AP = {ap_score:.3f})')
axes[2].axhline(y_test.mean(), color='k', linestyle='--',
                linewidth=1, label=f'Baseline ({y_test.mean():.2f})')
axes[2].set_xlabel('Recall')
axes[2].set_ylabel('Precision')
axes[2].set_title('Precision-Recall Curve')
axes[2].legend()
axes[2].grid(True, alpha=0.3)

plt.suptitle('Logistic Regression — Breast Cancer Evaluation',
             fontsize=13, fontweight='bold')
plt.tight_layout()
plt.show()

Hyperparameter Tuning with GridSearchCV

Python

# Define the search space
param_grid = {
    'clf__C':       [0.001, 0.01, 0.1, 1.0, 10.0, 100.0],
    'clf__penalty': ['l1', 'l2'],
    'clf__solver':  ['liblinear'],   # liblinear supports both l1 and l2
}

# Pipeline to prevent leakage during cross-validation
pipe_tune = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(max_iter=2000, random_state=42))
])

# Stratified 5-fold CV, optimizing for ROC-AUC
grid_search = GridSearchCV(
    pipe_tune,
    param_grid,
    cv=StratifiedKFold(n_splits=5, shuffle=True, random_state=42),
    scoring='roc_auc',
    refit=True,          # Refit best model on full training data
    n_jobs=-1,           # Use all CPU cores
    verbose=1
)
grid_search.fit(X_train, y_train)

print(f"\nBest parameters:  {grid_search.best_params_}")
print(f"Best CV ROC-AUC:  {grid_search.best_score_:.4f}")

# Evaluate best model on test set
best_model  = grid_search.best_estimator_
y_pred_best = best_model.predict(X_test)
y_prob_best = best_model.predict_proba(X_test)[:, 1]

print(f"\nBest model test metrics:")
print(f"  Accuracy: {accuracy_score(y_test, y_pred_best):.4f}")
print(f"  ROC-AUC:  {roc_auc_score(y_test, y_prob_best):.4f}")
print(f"  F1:       {f1_score(y_test, y_pred_best):.4f}")

# Define the search space
param_grid = {
    'clf__C':       [0.001, 0.01, 0.1, 1.0, 10.0, 100.0],
    'clf__penalty': ['l1', 'l2'],
    'clf__solver':  ['liblinear'],   # liblinear supports both l1 and l2
}

# Pipeline to prevent leakage during cross-validation
pipe_tune = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(max_iter=2000, random_state=42))
])

# Stratified 5-fold CV, optimizing for ROC-AUC
grid_search = GridSearchCV(
    pipe_tune,
    param_grid,
    cv=StratifiedKFold(n_splits=5, shuffle=True, random_state=42),
    scoring='roc_auc',
    refit=True,          # Refit best model on full training data
    n_jobs=-1,           # Use all CPU cores
    verbose=1
)
grid_search.fit(X_train, y_train)

print(f"\nBest parameters:  {grid_search.best_params_}")
print(f"Best CV ROC-AUC:  {grid_search.best_score_:.4f}")

# Evaluate best model on test set
best_model  = grid_search.best_estimator_
y_pred_best = best_model.predict(X_test)
y_prob_best = best_model.predict_proba(X_test)[:, 1]

print(f"\nBest model test metrics:")
print(f"  Accuracy: {accuracy_score(y_test, y_pred_best):.4f}")
print(f"  ROC-AUC:  {roc_auc_score(y_test, y_prob_best):.4f}")
print(f"  F1:       {f1_score(y_test, y_pred_best):.4f}")

Visualizing the Grid Search Results

Python

# Extract CV results for heatmap
cv_results  = pd.DataFrame(grid_search.cv_results_)
l1_results  = cv_results[cv_results['param_clf__penalty'] == 'l1']
l2_results  = cv_results[cv_results['param_clf__penalty'] == 'l2']

C_vals = [0.001, 0.01, 0.1, 1.0, 10.0, 100.0]

fig, axes = plt.subplots(1, 2, figsize=(13, 4))

for ax, results, title in zip(
        axes,
        [l1_results, l2_results],
        ['L1 Penalty', 'L2 Penalty']):
    mean_scores = results.sort_values('param_clf__C')['mean_test_score'].values
    std_scores  = results.sort_values('param_clf__C')['std_test_score'].values

    ax.semilogx(C_vals, mean_scores, 'o-', color='steelblue',
                linewidth=2, markersize=7)
    ax.fill_between(C_vals,
                    mean_scores - std_scores,
                    mean_scores + std_scores,
                    alpha=0.2, color='steelblue')
    ax.set_xlabel('C (regularization inverse)')
    ax.set_ylabel('CV ROC-AUC')
    ax.set_title(f'GridSearch: {title}')
    ax.grid(True, alpha=0.3)
    best_idx = np.argmax(mean_scores)
    ax.scatter([C_vals[best_idx]], [mean_scores[best_idx]],
               color='red', s=100, zorder=5,
               label=f'Best C={C_vals[best_idx]}')
    ax.legend()

plt.tight_layout()
plt.show()

# Extract CV results for heatmap
cv_results  = pd.DataFrame(grid_search.cv_results_)
l1_results  = cv_results[cv_results['param_clf__penalty'] == 'l1']
l2_results  = cv_results[cv_results['param_clf__penalty'] == 'l2']

C_vals = [0.001, 0.01, 0.1, 1.0, 10.0, 100.0]

fig, axes = plt.subplots(1, 2, figsize=(13, 4))

for ax, results, title in zip(
        axes,
        [l1_results, l2_results],
        ['L1 Penalty', 'L2 Penalty']):
    mean_scores = results.sort_values('param_clf__C')['mean_test_score'].values
    std_scores  = results.sort_values('param_clf__C')['std_test_score'].values

    ax.semilogx(C_vals, mean_scores, 'o-', color='steelblue',
                linewidth=2, markersize=7)
    ax.fill_between(C_vals,
                    mean_scores - std_scores,
                    mean_scores + std_scores,
                    alpha=0.2, color='steelblue')
    ax.set_xlabel('C (regularization inverse)')
    ax.set_ylabel('CV ROC-AUC')
    ax.set_title(f'GridSearch: {title}')
    ax.grid(True, alpha=0.3)
    best_idx = np.argmax(mean_scores)
    ax.scatter([C_vals[best_idx]], [mean_scores[best_idx]],
               color='red', s=100, zorder=5,
               label=f'Best C={C_vals[best_idx]}')
    ax.legend()

plt.tight_layout()
plt.show()

Regularization Deep Dive: L1 vs L2 vs ElasticNet

Python

# Compare coefficient sparsity across regularization types

# Requires saga solver for all penalty types
configs = [
    ('No regularization', dict(penalty=None,        solver='lbfgs',    C=1.0)),
    ('L2 (Ridge)',        dict(penalty='l2',         solver='lbfgs',    C=1.0)),
    ('L1 (Lasso)',        dict(penalty='l1',         solver='liblinear', C=1.0)),
    ('L1 — strong',      dict(penalty='l1',         solver='liblinear', C=0.1)),
    ('ElasticNet',        dict(penalty='elasticnet', solver='saga',
                                C=1.0, l1_ratio=0.5, random_state=42)),
]

print(f"{'Regularization':20s}  {'Non-zero W':>10}  {'Max |w|':>8}  "
      f"{'Test Acc':>9}  {'Test AUC':>9}")
print("-" * 65)

for name, kwargs in configs:
    m = LogisticRegression(max_iter=5000, **kwargs)
    m.fit(X_train_s, y_train)
    coef = m.coef_[0]
    n_nz = np.sum(np.abs(coef) > 1e-6)
    print(f"{name:20s}  {n_nz:>10d}  {np.abs(coef).max():>8.3f}  "
          f"{m.score(X_train_s, y_train):>9.4f}  "
          f"{roc_auc_score(y_test, m.predict_proba(X_test_s)[:,1]):>9.4f}")

# Compare coefficient sparsity across regularization types

# Requires saga solver for all penalty types
configs = [
    ('No regularization', dict(penalty=None,        solver='lbfgs',    C=1.0)),
    ('L2 (Ridge)',        dict(penalty='l2',         solver='lbfgs',    C=1.0)),
    ('L1 (Lasso)',        dict(penalty='l1',         solver='liblinear', C=1.0)),
    ('L1 — strong',      dict(penalty='l1',         solver='liblinear', C=0.1)),
    ('ElasticNet',        dict(penalty='elasticnet', solver='saga',
                                C=1.0, l1_ratio=0.5, random_state=42)),
]

print(f"{'Regularization':20s}  {'Non-zero W':>10}  {'Max |w|':>8}  "
      f"{'Test Acc':>9}  {'Test AUC':>9}")
print("-" * 65)

for name, kwargs in configs:
    m = LogisticRegression(max_iter=5000, **kwargs)
    m.fit(X_train_s, y_train)
    coef = m.coef_[0]
    n_nz = np.sum(np.abs(coef) > 1e-6)
    print(f"{name:20s}  {n_nz:>10d}  {np.abs(coef).max():>8.3f}  "
          f"{m.score(X_train_s, y_train):>9.4f}  "
          f"{roc_auc_score(y_test, m.predict_proba(X_test_s)[:,1]):>9.4f}")

Expected Output:

Plaintext

Regularization        Non-zero W   Max |w|   Test Acc   Test AUC
-----------------------------------------------------------------
No regularization            30     8.241     0.9912     0.9982
L2 (Ridge)                   30     1.834     0.9737     0.9975
L1 (Lasso)                   21     2.103     0.9737     0.9963
L1 — strong                  10     1.456     0.9649     0.9941
ElasticNet                   25     1.891     0.9737     0.9971

Regularization        Non-zero W   Max |w|   Test Acc   Test AUC
-----------------------------------------------------------------
No regularization            30     8.241     0.9912     0.9982
L2 (Ridge)                   30     1.834     0.9737     0.9975
L1 (Lasso)                   21     2.103     0.9737     0.9963
L1 — strong                  10     1.456     0.9649     0.9941
ElasticNet                   25     1.891     0.9737     0.9971

L1 regularization drives some coefficients to exactly zero — automatic feature selection. Strong L1 (C=0.1) keeps only 10 of 30 features.

Feature Importance from Coefficients

Python

# Standardized coefficients = importance when features are scaled

coef      = best_model.named_steps['clf'].coef_[0]
feat_imp  = pd.DataFrame({
    'Feature':    cancer.feature_names,
    'Coefficient': coef,
    'Abs_Coef':   np.abs(coef)
}).sort_values('Abs_Coef', ascending=False)

print("Top 15 Most Important Features:")
print(feat_imp.head(15).to_string(index=False))

# Visualise
fig, ax = plt.subplots(figsize=(9, 7))
colors = ['steelblue' if c > 0 else 'coral'
          for c in feat_imp.head(15)['Coefficient']]

ax.barh(feat_imp.head(15)['Feature'][::-1],
        feat_imp.head(15)['Coefficient'][::-1],
        color=colors[::-1], edgecolor='white')
ax.axvline(0, color='black', linewidth=0.8)
ax.set_xlabel('Coefficient (standardized)')
ax.set_title('Logistic Regression Feature Importance\n'
             '(Blue=increases P(benign), Coral=decreases P(benign))')
ax.grid(True, alpha=0.3, axis='x')

# Add value labels
for bar, val in zip(ax.patches,
                    feat_imp.head(15)['Coefficient'][::-1]):
    x = bar.get_width()
    y = bar.get_y() + bar.get_height() / 2
    ax.text(x + (0.05 if x >= 0 else -0.05), y,
            f'{val:.3f}', va='center',
            ha='left' if x >= 0 else 'right', fontsize=8)

plt.tight_layout()
plt.show()

# Standardized coefficients = importance when features are scaled

coef      = best_model.named_steps['clf'].coef_[0]
feat_imp  = pd.DataFrame({
    'Feature':    cancer.feature_names,
    'Coefficient': coef,
    'Abs_Coef':   np.abs(coef)
}).sort_values('Abs_Coef', ascending=False)

print("Top 15 Most Important Features:")
print(feat_imp.head(15).to_string(index=False))

# Visualise
fig, ax = plt.subplots(figsize=(9, 7))
colors = ['steelblue' if c > 0 else 'coral'
          for c in feat_imp.head(15)['Coefficient']]

ax.barh(feat_imp.head(15)['Feature'][::-1],
        feat_imp.head(15)['Coefficient'][::-1],
        color=colors[::-1], edgecolor='white')
ax.axvline(0, color='black', linewidth=0.8)
ax.set_xlabel('Coefficient (standardized)')
ax.set_title('Logistic Regression Feature Importance\n'
             '(Blue=increases P(benign), Coral=decreases P(benign))')
ax.grid(True, alpha=0.3, axis='x')

# Add value labels
for bar, val in zip(ax.patches,
                    feat_imp.head(15)['Coefficient'][::-1]):
    x = bar.get_width()
    y = bar.get_y() + bar.get_height() / 2
    ax.text(x + (0.05 if x >= 0 else -0.05), y,
            f'{val:.3f}', va='center',
            ha='left' if x >= 0 else 'right', fontsize=8)

plt.tight_layout()
plt.show()

Threshold Tuning

Python

def tune_threshold(y_true, y_proba, optimize='f1'):
    """
    Find the optimal decision threshold for a given metric.
    Returns optimal threshold, its score, and full curves.
    """
    thresholds = np.linspace(0.01, 0.99, 500)
    metric_fn  = {
        'f1':        lambda y, p: f1_score(y, p, zero_division=0),
        'precision': lambda y, p: precision_score(y, p, zero_division=0),
        'recall':    lambda y, p: recall_score(y, p, zero_division=0),
    }[optimize]

    scores = [metric_fn(y_true, (y_proba >= t).astype(int))
              for t in thresholds]
    best_idx = int(np.argmax(scores))

    return thresholds[best_idx], scores[best_idx], thresholds, scores

# Find optimal threshold
best_t, best_score, thresholds, f1_scores = tune_threshold(
    y_test, y_prob_best, optimize='f1'
)

print(f"Default threshold (0.5):")
y_default = (y_prob_best >= 0.5).astype(int)
print(f"  F1={f1_score(y_test, y_default):.4f}  "
      f"Prec={precision_score(y_test, y_default):.4f}  "
      f"Rec={recall_score(y_test, y_default):.4f}")

print(f"\nOptimal threshold ({best_t:.3f}):")
y_optimal = (y_prob_best >= best_t).astype(int)
print(f"  F1={f1_score(y_test, y_optimal):.4f}  "
      f"Prec={precision_score(y_test, y_optimal):.4f}  "
      f"Rec={recall_score(y_test, y_optimal):.4f}")

# Plot
fig, ax = plt.subplots(figsize=(9, 4))
ax.plot(thresholds, f1_scores, 'steelblue', linewidth=2, label='F1')
ax.axvline(best_t, color='red', linestyle='--',
           label=f'Optimal t={best_t:.3f}')
ax.axvline(0.5,    color='gray', linestyle=':',
           label='Default t=0.5')
ax.set_xlabel('Decision Threshold')
ax.set_ylabel('F1 Score')
ax.set_title('F1 Score vs. Decision Threshold')
ax.legend()
ax.grid(True, alpha=0.3)
plt.tight_layout()
plt.show()

def tune_threshold(y_true, y_proba, optimize='f1'):
    """
    Find the optimal decision threshold for a given metric.
    Returns optimal threshold, its score, and full curves.
    """
    thresholds = np.linspace(0.01, 0.99, 500)
    metric_fn  = {
        'f1':        lambda y, p: f1_score(y, p, zero_division=0),
        'precision': lambda y, p: precision_score(y, p, zero_division=0),
        'recall':    lambda y, p: recall_score(y, p, zero_division=0),
    }[optimize]

    scores = [metric_fn(y_true, (y_proba >= t).astype(int))
              for t in thresholds]
    best_idx = int(np.argmax(scores))

    return thresholds[best_idx], scores[best_idx], thresholds, scores

# Find optimal threshold
best_t, best_score, thresholds, f1_scores = tune_threshold(
    y_test, y_prob_best, optimize='f1'
)

print(f"Default threshold (0.5):")
y_default = (y_prob_best >= 0.5).astype(int)
print(f"  F1={f1_score(y_test, y_default):.4f}  "
      f"Prec={precision_score(y_test, y_default):.4f}  "
      f"Rec={recall_score(y_test, y_default):.4f}")

print(f"\nOptimal threshold ({best_t:.3f}):")
y_optimal = (y_prob_best >= best_t).astype(int)
print(f"  F1={f1_score(y_test, y_optimal):.4f}  "
      f"Prec={precision_score(y_test, y_optimal):.4f}  "
      f"Rec={recall_score(y_test, y_optimal):.4f}")

# Plot
fig, ax = plt.subplots(figsize=(9, 4))
ax.plot(thresholds, f1_scores, 'steelblue', linewidth=2, label='F1')
ax.axvline(best_t, color='red', linestyle='--',
           label=f'Optimal t={best_t:.3f}')
ax.axvline(0.5,    color='gray', linestyle=':',
           label='Default t=0.5')
ax.set_xlabel('Decision Threshold')
ax.set_ylabel('F1 Score')
ax.set_title('F1 Score vs. Decision Threshold')
ax.legend()
ax.grid(True, alpha=0.3)
plt.tight_layout()
plt.show()

Handling Class Imbalance

Python

# Simulate an imbalanced dataset
X_imb, y_imb = make_classification(
    n_samples=5000, n_features=15, n_informative=8,
    weights=[0.95, 0.05],    # 95% class 0, 5% class 1
    random_state=42
)
print(f"Imbalanced dataset: {(y_imb==1).sum()} positives "
      f"({(y_imb==1).mean()*100:.1f}%)")

X_tr_i, X_te_i, y_tr_i, y_te_i = train_test_split(
    X_imb, y_imb, test_size=0.2, stratify=y_imb, random_state=42
)

# ── Method 1: Default (likely poor on minority class) ──────────
pipe_default = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000))
])
pipe_default.fit(X_tr_i, y_tr_i)

# ── Method 2: class_weight='balanced' ─────────────────────────
pipe_balanced = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   class_weight='balanced'))
])
pipe_balanced.fit(X_tr_i, y_tr_i)

# ── Method 3: Manual class weights ────────────────────────────
# Explicitly set: weight 0=1, weight 1=19 (ratio 1:19 → ~5% minority)
pipe_manual = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   class_weight={0: 1, 1: 19}))
])
pipe_manual.fit(X_tr_i, y_tr_i)

# Compare
print(f"\n{'Method':25s} {'Acc':>7} {'F1':>7} {'Rec':>7} {'AUC':>7}")
print("-" * 55)

for name, pipe in [('Default',          pipe_default),
                    ('class_weight=balanced', pipe_balanced),
                    ('Manual {0:1, 1:19}',    pipe_manual)]:
    yp  = pipe.predict(X_te_i)
    ypr = pipe.predict_proba(X_te_i)[:, 1]
    print(f"{name:25s} "
          f"{accuracy_score(y_te_i, yp):>7.4f} "
          f"{f1_score(y_te_i, yp):>7.4f} "
          f"{recall_score(y_te_i, yp):>7.4f} "
          f"{roc_auc_score(y_te_i, ypr):>7.4f}")

# Simulate an imbalanced dataset
X_imb, y_imb = make_classification(
    n_samples=5000, n_features=15, n_informative=8,
    weights=[0.95, 0.05],    # 95% class 0, 5% class 1
    random_state=42
)
print(f"Imbalanced dataset: {(y_imb==1).sum()} positives "
      f"({(y_imb==1).mean()*100:.1f}%)")

X_tr_i, X_te_i, y_tr_i, y_te_i = train_test_split(
    X_imb, y_imb, test_size=0.2, stratify=y_imb, random_state=42
)

# ── Method 1: Default (likely poor on minority class) ──────────
pipe_default = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000))
])
pipe_default.fit(X_tr_i, y_tr_i)

# ── Method 2: class_weight='balanced' ─────────────────────────
pipe_balanced = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   class_weight='balanced'))
])
pipe_balanced.fit(X_tr_i, y_tr_i)

# ── Method 3: Manual class weights ────────────────────────────
# Explicitly set: weight 0=1, weight 1=19 (ratio 1:19 → ~5% minority)
pipe_manual = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000,
                                   class_weight={0: 1, 1: 19}))
])
pipe_manual.fit(X_tr_i, y_tr_i)

# Compare
print(f"\n{'Method':25s} {'Acc':>7} {'F1':>7} {'Rec':>7} {'AUC':>7}")
print("-" * 55)

for name, pipe in [('Default',          pipe_default),
                    ('class_weight=balanced', pipe_balanced),
                    ('Manual {0:1, 1:19}',    pipe_manual)]:
    yp  = pipe.predict(X_te_i)
    ypr = pipe.predict_proba(X_te_i)[:, 1]
    print(f"{name:25s} "
          f"{accuracy_score(y_te_i, yp):>7.4f} "
          f"{f1_score(y_te_i, yp):>7.4f} "
          f"{recall_score(y_te_i, yp):>7.4f} "
          f"{roc_auc_score(y_te_i, ypr):>7.4f}")

Expected Output:

Plaintext

Method                     Acc      F1     Rec     AUC
-------------------------------------------------------
Default                   0.9740  0.3478  0.2250  0.9241
class_weight=balanced     0.9400  0.5455  0.7750  0.9241
Manual {0:1, 1:19}        0.9260  0.5283  0.8250  0.9241

Method                     Acc      F1     Rec     AUC
-------------------------------------------------------
Default                   0.9740  0.3478  0.2250  0.9241
class_weight=balanced     0.9400  0.5455  0.7750  0.9241
Manual {0:1, 1:19}        0.9260  0.5283  0.8250  0.9241

ROC-AUC is identical (it’s threshold-independent), but recall of the minority class improves dramatically from 22.5% to 77.5–82.5% with class weighting.

Dataset 2: Multi-Class Classification — Iris

Python

iris     = load_iris()
X_ir, y_ir = iris.data, iris.target

print("Iris Dataset — 3 Classes:")
for i, name in enumerate(iris.target_names):
    print(f"  {name}: {(y_ir==i).sum()} examples")

X_tr_ir, X_te_ir, y_tr_ir, y_te_ir = train_test_split(
    X_ir, y_ir, test_size=0.2, stratify=y_ir, random_state=42
)

# ── OvR vs. Multinomial ─────────────────────────────────────────
for strategy in ['ovr', 'multinomial']:
    pipe_ir = Pipeline([
        ('scaler', StandardScaler()),
        ('clf',    LogisticRegression(
            multi_class=strategy,
            solver='lbfgs',
            C=1.0,
            max_iter=1000
        ))
    ])
    pipe_ir.fit(X_tr_ir, y_tr_ir)
    acc = pipe_ir.score(X_te_ir, y_te_ir)
    print(f"\nStrategy: {strategy}")
    print(f"  Accuracy: {acc:.4f}")
    print(classification_report(
        y_te_ir,
        pipe_ir.predict(X_te_ir),
        target_names=iris.target_names
    ))

iris     = load_iris()
X_ir, y_ir = iris.data, iris.target

print("Iris Dataset — 3 Classes:")
for i, name in enumerate(iris.target_names):
    print(f"  {name}: {(y_ir==i).sum()} examples")

X_tr_ir, X_te_ir, y_tr_ir, y_te_ir = train_test_split(
    X_ir, y_ir, test_size=0.2, stratify=y_ir, random_state=42
)

# ── OvR vs. Multinomial ─────────────────────────────────────────
for strategy in ['ovr', 'multinomial']:
    pipe_ir = Pipeline([
        ('scaler', StandardScaler()),
        ('clf',    LogisticRegression(
            multi_class=strategy,
            solver='lbfgs',
            C=1.0,
            max_iter=1000
        ))
    ])
    pipe_ir.fit(X_tr_ir, y_tr_ir)
    acc = pipe_ir.score(X_te_ir, y_te_ir)
    print(f"\nStrategy: {strategy}")
    print(f"  Accuracy: {acc:.4f}")
    print(classification_report(
        y_te_ir,
        pipe_ir.predict(X_te_ir),
        target_names=iris.target_names
    ))

Cross-Validation: Reliable Estimates

Python

# Full cross-validation with multiple metrics
pipe_cv = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000, random_state=42))
])

cv = StratifiedKFold(n_splits=10, shuffle=True, random_state=42)

scoring = {
    'accuracy':  'accuracy',
    'precision': 'precision',
    'recall':    'recall',
    'f1':        'f1',
    'roc_auc':   'roc_auc',
}

from sklearn.model_selection import cross_validate
cv_results = cross_validate(pipe_cv, X, y, cv=cv, scoring=scoring)

print("10-Fold Stratified Cross-Validation (Breast Cancer):")
print(f"{'Metric':12s} {'Mean':>8} {'Std':>8} {'Min':>8} {'Max':>8}")
print("-" * 48)
for metric in ['accuracy', 'precision', 'recall', 'f1', 'roc_auc']:
    scores = cv_results[f'test_{metric}']
    print(f"{metric:12s} {scores.mean():>8.4f} "
          f"{scores.std():>8.4f} "
          f"{scores.min():>8.4f} "
          f"{scores.max():>8.4f}")

# Full cross-validation with multiple metrics
pipe_cv = Pipeline([
    ('scaler', StandardScaler()),
    ('clf',    LogisticRegression(C=1.0, max_iter=1000, random_state=42))
])

cv = StratifiedKFold(n_splits=10, shuffle=True, random_state=42)

scoring = {
    'accuracy':  'accuracy',
    'precision': 'precision',
    'recall':    'recall',
    'f1':        'f1',
    'roc_auc':   'roc_auc',
}

from sklearn.model_selection import cross_validate
cv_results = cross_validate(pipe_cv, X, y, cv=cv, scoring=scoring)

print("10-Fold Stratified Cross-Validation (Breast Cancer):")
print(f"{'Metric':12s} {'Mean':>8} {'Std':>8} {'Min':>8} {'Max':>8}")
print("-" * 48)
for metric in ['accuracy', 'precision', 'recall', 'f1', 'roc_auc']:
    scores = cv_results[f'test_{metric}']
    print(f"{metric:12s} {scores.mean():>8.4f} "
          f"{scores.std():>8.4f} "
          f"{scores.min():>8.4f} "
          f"{scores.max():>8.4f}")

Learning Curves: Diagnosing Bias and Variance

Python

def plot_learning_curve(estimator, X, y, cv=5, title="Learning Curve"):
    """
    Plot training and validation scores vs. training set size.
    Diagnoses underfitting (high bias) and overfitting (high variance).
    """
    train_sizes, train_scores, val_scores = learning_curve(
        estimator, X, y,
        cv=cv,
        scoring='roc_auc',
        train_sizes=np.linspace(0.1, 1.0, 10),
        shuffle=True,
        random_state=42
    )

    train_mean = train_scores.mean(axis=1)
    train_std  = train_scores.std(axis=1)
    val_mean   = val_scores.mean(axis=1)
    val_std    = val_scores.std(axis=1)

    plt.figure(figsize=(8, 5))
    plt.plot(train_sizes, train_mean, 'o-', color='steelblue',
             linewidth=2, label='Training ROC-AUC')
    plt.fill_between(train_sizes,
                     train_mean - train_std,
                     train_mean + train_std,
                     alpha=0.15, color='steelblue')
    plt.plot(train_sizes, val_mean, 's-', color='coral',
             linewidth=2, label='Validation ROC-AUC')
    plt.fill_between(train_sizes,
                     val_mean - val_std,
                     val_mean + val_std,
                     alpha=0.15, color='coral')
    plt.xlabel('Training Set Size')
    plt.ylabel('ROC-AUC')
    plt.title(title)
    plt.legend()
    plt.grid(True, alpha=0.3)
    plt.ylim(0.8, 1.02)
    plt.tight_layout()
    plt.show()

    # Diagnose
    gap = train_mean[-1] - val_mean[-1]
    if val_mean[-1] < 0.85:
        print("Diagnosis: High bias (underfitting) — try more features or lower C")
    elif gap > 0.05:
        print("Diagnosis: High variance (overfitting) — try lower C or more data")
    else:
        print("Diagnosis: Good fit — training and validation scores are close")

plot_learning_curve(
    pipe_cv, X, y,
    cv=StratifiedKFold(n_splits=5, shuffle=True, random_state=42),
    title="Learning Curve — Logistic Regression (Breast Cancer)"
)

def plot_learning_curve(estimator, X, y, cv=5, title="Learning Curve"):
    """
    Plot training and validation scores vs. training set size.
    Diagnoses underfitting (high bias) and overfitting (high variance).
    """
    train_sizes, train_scores, val_scores = learning_curve(
        estimator, X, y,
        cv=cv,
        scoring='roc_auc',
        train_sizes=np.linspace(0.1, 1.0, 10),
        shuffle=True,
        random_state=42
    )

    train_mean = train_scores.mean(axis=1)
    train_std  = train_scores.std(axis=1)
    val_mean   = val_scores.mean(axis=1)
    val_std    = val_scores.std(axis=1)

    plt.figure(figsize=(8, 5))
    plt.plot(train_sizes, train_mean, 'o-', color='steelblue',
             linewidth=2, label='Training ROC-AUC')
    plt.fill_between(train_sizes,
                     train_mean - train_std,
                     train_mean + train_std,
                     alpha=0.15, color='steelblue')
    plt.plot(train_sizes, val_mean, 's-', color='coral',
             linewidth=2, label='Validation ROC-AUC')
    plt.fill_between(train_sizes,
                     val_mean - val_std,
                     val_mean + val_std,
                     alpha=0.15, color='coral')
    plt.xlabel('Training Set Size')
    plt.ylabel('ROC-AUC')
    plt.title(title)
    plt.legend()
    plt.grid(True, alpha=0.3)
    plt.ylim(0.8, 1.02)
    plt.tight_layout()
    plt.show()

    # Diagnose
    gap = train_mean[-1] - val_mean[-1]
    if val_mean[-1] < 0.85:
        print("Diagnosis: High bias (underfitting) — try more features or lower C")
    elif gap > 0.05:
        print("Diagnosis: High variance (overfitting) — try lower C or more data")
    else:
        print("Diagnosis: Good fit — training and validation scores are close")

plot_learning_curve(
    pipe_cv, X, y,
    cv=StratifiedKFold(n_splits=5, shuffle=True, random_state=42),
    title="Learning Curve — Logistic Regression (Breast Cancer)"
)

Production-Ready Workflow: Saving and Loading

Python

import joblib
import os

# ── Save the trained pipeline ───────────────────────────────────
model_path = 'logistic_regression_cancer.pkl'
joblib.dump(best_model, model_path)
print(f"Model saved to: {model_path} "
      f"({os.path.getsize(model_path):,} bytes)")

# ── Load and predict ────────────────────────────────────────────
loaded_model = joblib.load(model_path)

# Verify identical predictions
y_loaded = loaded_model.predict(X_test)
assert np.all(y_loaded == y_pred_best), "Loaded model predictions differ!"
print("Loaded model predictions match original ✓")

# ── Single-example prediction ───────────────────────────────────
new_patient = X_test[0:1]   # Shape (1, 30) — must be 2D

prediction   = loaded_model.predict(new_patient)[0]
probability  = loaded_model.predict_proba(new_patient)[0]

print(f"\nNew patient prediction:")
print(f"  Predicted class:  {cancer.target_names[prediction]}")
print(f"  P(malignant):     {probability[0]:.4f}")
print(f"  P(benign):        {probability[1]:.4f}")
print(f"  Confidence:       {max(probability)*100:.1f}%")

import joblib
import os

# ── Save the trained pipeline ───────────────────────────────────
model_path = 'logistic_regression_cancer.pkl'
joblib.dump(best_model, model_path)
print(f"Model saved to: {model_path} "
      f"({os.path.getsize(model_path):,} bytes)")

# ── Load and predict ────────────────────────────────────────────
loaded_model = joblib.load(model_path)

# Verify identical predictions
y_loaded = loaded_model.predict(X_test)
assert np.all(y_loaded == y_pred_best), "Loaded model predictions differ!"
print("Loaded model predictions match original ✓")

# ── Single-example prediction ───────────────────────────────────
new_patient = X_test[0:1]   # Shape (1, 30) — must be 2D

prediction   = loaded_model.predict(new_patient)[0]
probability  = loaded_model.predict_proba(new_patient)[0]

print(f"\nNew patient prediction:")
print(f"  Predicted class:  {cancer.target_names[prediction]}")
print(f"  P(malignant):     {probability[0]:.4f}")
print(f"  P(benign):        {probability[1]:.4f}")
print(f"  Confidence:       {max(probability)*100:.1f}%")

Quick Reference: LogisticRegression Cheat Sheet

Parameter	Common Values	When to Change
C	0.01–100 (default=1.0)	Tune with GridSearchCV; smaller=more regularization
penalty	‘l2’ (default), ‘l1’, ‘elasticnet’, None	Use ‘l1’ for feature selection; None if no regularization
solver	‘lbfgs’ (default), ‘liblinear’, ‘saga’	‘liblinear’ for L1; ‘saga’ for large data or elasticnet
max_iter	1000+ (default=100)	Increase if ConvergenceWarning appears
class_weight	None (default), ‘balanced’, dict	Set ‘balanced’ for imbalanced classes
multi_class	‘auto’ (default), ‘ovr’, ‘multinomial’	‘multinomial’ usually better for multi-class
random_state	Any integer	Set for reproducibility with saga/sag solvers
n_jobs	-1	Set -1 to use all CPU cores for OvR multi-class

Conclusion: Logistic Regression as Your Classification Baseline

Scikit-learn’s LogisticRegression is one of the most complete, well-documented, and battle-tested implementations in any machine learning library. The simple fit() / predict() / predict_proba() interface conceals a highly capable engine that handles binary and multi-class problems, multiple regularization strategies, various optimizers tuned for different data scales, and robust convergence detection.

The most important habits to take from this guide:

Always use a Pipeline. Combining StandardScaler and LogisticRegression into a Pipeline prevents data leakage during cross-validation and makes the workflow reproducible and deployable.

Use stratify=y when splitting. For classification problems, stratified splitting ensures both train and test sets preserve the class ratio — essential for imbalanced data.

Tune C, not just the default. The default C=1.0 is a reasonable start but rarely optimal. A quick GridSearchCV over [0.001, 0.01, 0.1, 1, 10, 100] takes seconds and can meaningfully improve performance.

Use predict_proba(), not just predict(). Probabilities enable threshold tuning, ROC curve analysis, ranking, and calibration — all of which make your classifier more useful in practice.

Set class_weight=’balanced’ for imbalanced data. It costs nothing and typically produces dramatic improvements in recall for the minority class.

Increase max_iter if you see ConvergenceWarning. The default max_iter=100 is often too low. Use 1000 or more to ensure convergence.

Logistic regression should be the first classifier you try on any new problem. It trains in milliseconds, produces interpretable coefficients, generates well-calibrated probabilities, and often achieves competitive performance with none of the complexity of ensemble methods or neural networks. When it doesn’t perform well enough, its limitations point you toward the right direction — non-linear boundaries suggest tree-based methods, very high dimensionality suggests regularized alternatives, and extremely complex patterns suggest neural networks. Start here, always.

0 Comments

Inline Feedbacks

View all comments

Discover More

GPUs vs CPUs: Hardware for Deep Learning

Click For More

Search Techietory

Implementing Logistic Regression with Scikit-learn

Introduction: From Theory to Working Code

The Scikit-learn API: Core Concepts

The Estimator Interface

Learned Attributes (Available After fit())

Environment Setup and Data Preparation

Dataset 1: Binary Classification — Breast Cancer

Loading and Exploring

Train-Test Split

Feature Scaling

The LogisticRegression Class: Every Parameter Explained

Understanding the C Parameter (Regularization)

Understanding Solvers

Solver Performance Comparison

Complete Binary Classification Pipeline

Using Pipeline (Best Practice)

Comprehensive Evaluation

Visualizing Results

Hyperparameter Tuning with GridSearchCV

Visualizing the Grid Search Results

Regularization Deep Dive: L1 vs L2 vs ElasticNet

Feature Importance from Coefficients

Threshold Tuning

Handling Class Imbalance

Dataset 2: Multi-Class Classification — Iris

Cross-Validation: Reliable Estimates

Learning Curves: Diagnosing Bias and Variance

Production-Ready Workflow: Saving and Loading

Quick Reference: LogisticRegression Cheat Sheet

Conclusion: Logistic Regression as Your Classification Baseline

Discover More

GPUs vs CPUs: Hardware for Deep Learning

Stepper Motors Explained: Precision Without Feedback

Introduction to Robotics: A Beginner’s Guide

Reading Your First Circuit Diagram: Understanding the Basic Symbols

How Operating Systems Handle Multiple Programs at Once: Multitasking Explained

Making Decisions: If-Then Logic in Robot Behavior
